Slot milling machine
The slot milling machine is used for milling chip slots for bank cards and telecommunication cards and is an economical machine suitable for medium and high capacities. The main features of the machine are its flexibility and modular design. The standardized milling capacity is up to 4500 UPH for bank cards and 8500 UPH for telecom cards.
Product DetailsProduct Parameters
Main features
Fully automatic card slot milling machine for standard contact and dual-interface cards, SIM cards
Graphics-based milling programming design
User-friendly operation, flexible modular design
Production processing modules
Optional card positioning and thickness measurement system
Availability: up to 95%
Yield rate: up to 99.7%
Technical Parameters
Slot milling accuracy: Cp>1.33
Milling accuracy: x, y = +/- 0.015 mm, z = +/- 0.01 mm
Throughput: up to 4500 UPH for bank cards and 8500 UPH for telecom cards; depends on material and product
| Designation | XW Slot milling machine |
| Card Materials | ABS,PVC,PETF,PETG,PC,PC-ABS |
| Card sizes | 85.6mm X 54mm X 0.5-0.8mm |
| Total power | 10KW |
| Electric power source | AC 380V 50/60HZ |
| Dimensions | L:2880mm X W:800mm X H:1800mm |
| Weights | About 1800Kg |
